VTL MACHINES |
| |
|
|
|
| |
| Double
Column VTL Machine |
| Model |
1500mm |
2000mm |
2500mm |
3000mm |
| Table Diameter standard |
1500 |
2000 |
2500 |
3000 |
| Maximum Turning Diameter |
1650 |
2300 |
2700 |
3200 |
| Maximum Distance From Table |
1400 |
1400 |
1500 |
1600 |
| Travels of Turret Head Center Towards Right From
Table Center |
800 |
1100 |
1100 |
1100 |
| Travel of R.H. Ram Head |
800 |
1100 |
1200 |
1300 |
| No, of Table Speeds |
6 |
6 |
6 |
6 |
| No. of Feeds per Revolution |
3 |
3 |
3 |
3 |
| H.P. of Main Motor Drive |
20HP |
25HP |
30HP |
35HP |
|
| |
| |
| |
|
| |
|
|
 |
|
|
|
